Mahr Digimar 817 CLT
Motorised height measurement instrument
Highly precise and intuitive, the Mahr Digimar 817 CLT height gauge offers fast accurate height measurement across precision applications from aerospace to automotive.
Available in three measuring ranges: 350mm, 600mm and 1,000mm, the Digimar boasts intuitive eye-level touch control for easy measurement and a variety of interfaces available for saving measurement data with fully traceable results.
The CLT is Intuitive and easy to operate via touch display without major training, it has a Tiltable and swivelling display for relaxed operation, Air bearing system and handles on both sides for easy jerk-free shifting. Function keys and a dynamic thumbwheel speed up and simplify handling, Powerful rechargeable battery for self sufficient operation
The Mahr Digimar 817 CLT height gauge enables you to measure lengths, distances, diameters, and the perpendicularity of components to micron level providing improvement to measurement capabilities of your testing process ensuring precision-made parts continuously deliver their expected performance.
Specifications
- Intuitive and fluid operation via touch display without major training expenditure
- Tiltable and swivelling display for relaxed operation
- Air bearing system and handles on both sides for easy, jerk-free shifting
- Function keys and a dynamic thumbwheel speed up and simplify handling
- Powerful rechargeable battery for self sufficient operation
- Extensive measurement and calculation functions
- Automated measurement proces via drag and drop
- Automatic squareness and straightness measurement (with accessories)
- Advanced 2D functions in the display and calculation settings
- Measuring range 0-350mm / 0-600mm / 0-1000mm
- Resolution 0.0001mm, 0.0005mm, 0.001mm, 0.005mm, 0.01mm
- Error limit (1.8 +L/600) L in mm
- Repeatability bores 1μm
- Repeatability planes 0.5μm
- Data interface 3 x USB 2.0, wireless
