Vision Swift Pro Duo

The only video measuring system to incorporate an ergonomic measuring microscope

Swift Pro Cam combines two measuring microscopes in a single, robust device, saving space and money.  Use video measuring for bulk and routine work, where the edges of features can be easily identified.  For more challenging subjects, with very low contrast between the feature and the background, the same user can switch to optical measurement. This greatly simplifies the entire process while also reducing the chance of different results from different users – increasing the degree of precision achieved.

The unique Dynascope  eyepiece-less technology provides high contrast, microscope-resolution images for easy, accurate measuring.

Whether  inspecting or measuring routine parts as part of your day-to-day quality assurance or have a more complex precision part to work on, the Vision Swift Duo Pro is the go-to metrology partner.

Its compact design means it can easily fit in quality control labs with limited space, or even on the shop floor.

Enquire
Request a Demo

Specifications

Why Choose Vision Swift Pro Duo?

  • Ideal for use on the shop floor as well as the QC lab.
  • Optical microsope and video measurement system in one
  • Advanced and robust measuring system in a compact size
  • Integrated Z axis encoder for accurate height and depth measurement
  • Integrated software driven lighting control
  • Product Highlights

  • Segmented LED ring light for better surface illumination and edge detection
  • Designed especially for toolmakers and shop floor operators
  • Take accurate measurements in seconds, with no need for pre-programming
  • Z-axis variant for height measurement
  • Patented optical ergonomic microscope offers high resolution surface inspection
  • Key Numbers

  • 200mm x 100mm x 98mm precision measuring stage
  • 12KG maximum load
  • 10μm measurement accuracy
  • 10X, 20X, 50X & 100X magnification range
  • Downloads

    Case Study

    Laser Micromachining Limited adopt the Vision Swift Pro Duo

    Laser Micromachining Limited (LML) supplies high-quality, fast turnaround contract manufacturing services to industry, enabling the rapid and cost-effective production of micro-products.

    Read More
